超声引导下球囊扩张术治疗动静脉内瘘狭窄的疗效观察

doi:10.11958/20252772

摘要/Abstract

摘要：

目的观察超声引导下球囊扩张术治疗动静脉内瘘狭窄的效果及再狭窄率。方法回顾性分析78例动静脉内瘘狭窄患者的临床资料，按手术方式的不同分组，将数字减影血管造影（DSA）下行球囊扩张治疗的38例患者纳入DSA组，将超声引导下球囊扩张术治疗的40例患者纳入超声引导组，观察2组患者一次穿刺成功率、手术用时、术中出血量、术后内瘘开始使用时间等手术情况，比较术后临床指标、术后再狭窄及术后并发症发生情况。结果超声引导组较DSA组一次穿刺成功率更高，手术用时更短（P<0.05），2组术中出血量、术后内瘘开始使用时间相比差异无统计学意义（P>0.05）；2组术后7 d的动静脉内瘘狭窄处内径大小、透析血流量、内瘘自然血流量、横截面积相较术前均升高（P<0.05）；术后7 d，超声引导组相较DSA组内径大小、透析血流量、内瘘自然血流量明显更高（P<0.05）；2组患者术后横截面积相比差异无统计学意义（P>0.05）；2组患者术后1个月内均无再狭窄发生，术后3个月的再狭窄率相比差异无统计学意义（P>0.05），超声引导组相较DSA组在术后6、9个月时的再狭窄率更低（P<0.05）；2组患者术后并发症总发生率比较差异无统计学意义（P>0.05）。结论超声引导下球囊扩张术治疗动静脉内瘘狭窄可有效改善狭窄处内径，手术用时少，提高透析血流量，且再狭窄风险低，术后并发症少。

关键词: 动静脉瘘, 动静脉内瘘狭窄, 超声引导下球囊扩张术, 再狭窄率

Abstract:

Objective To observe the effect and restenosis rate of ultrasound-guided balloon dilatation in the treatment of arteriovenous fistula stenosis. Methods The clinical data of 78 patients with arteriovenous fistula stenosis were retrospectively analyzed. The above patients were grouped by different surgical methods. Thirty-eight patients who received balloon dilatation under digital subtraction angiography (DSA) were included in the DSA group, and 40 cases who adopted ultrasound-guided balloon dilatation were enrolled as the ultrasound-guided group. The surgical conditions (success rate of one-time puncture, surgical time, intraoperative blood loss and postoperative fistula starting time) were observed in the two groups of patients. The postoperative clinical indicators, postoperative restenosis and occurrence of postoperative complications were compared. Results Compared with the DSA group, the success rate of one-time puncture, was higher, and the surgical time was shorter in the ultrasound-guided group (P<0.05), but there were no significant differences in the intraoperative blood loss and postoperative fistula starting time between the two groups (P>0.05). The internal diameter, dialysis blood flow volume, internal fistula natural blood flow and cross-sectional area of the arteriovenous fistula stenosis were increased at 7 days after surgery compared with those before surgery in the two groups (P<0.05). The internal diameter, dialysis blood flow volume and internal fistula natural blood flow in the ultrasound-guided group at 7 days after surgery were significantly higher than those in the DSA group (P<0.05). There was no significant difference in postoperative cross-sectional area between the two groups of patients (P>0.05). No restenosis occurred within 1 month after surgery in the two groups, and there was no significant difference in the restenosis rate at 3 months after surgery between the two groups of patients (P>0.05). The restenosis rates at 6 and 9 months after surgery were lower in the ultrasound-guided group than those in the DSA group (P<0.05). There was no statistical difference in total incidence rate of postoperative complications between the two groups of patients (P>0.05). Conclusion Ultrasound-guided balloon dilatation in the treatment of arteriovenous fistula stenosis can effectively improve the inner diameter of the stenosis, exhibit quick surgery and increase the dialysis blood flow volume. In addition, it has low risk of restenosis and few postoperative complications.

Key words: arteriovenous fistula, arteriovenous fistula stenosis, ultrasound-guided balloon dilatation, restenosis rate

中图分类号:

R459.5

图/表 6

参考文献 19

[1]	李杰, 侯国存. 动静脉内瘘成形术相关新技术应用进展[J]. 中国血液净化, 2023, 22(4):287-291.
	LI J, HOU G C. Recent progresses in the application of new techniques relating to arteriovenous fistuloplasty[J]. Chin J Blood Purif, 2023, 22(4):287-291. doi:10.3969/j.issn.1671-4091.2023.04.009.
[2]	李丽华, 王卫华, 李玫, 等. 锁边缝合在内瘘血管吻合中的应用对动静脉内瘘通畅性的影响[J]. 中国血液净化, 2024, 23(8):620-624.
	LI L H, WANG W H, LI M, et al. Effect of overlock stitch for vascular anastomosis during internal fistula surgery on patency of the arteriovenous fistula[J]. Chin J Blood Purif, 2024, 23(8):620-624. doi:10.3969/j.issn.1671-4091.2024.08.011.
[3]	舒启沛, 张君, 尹娜, 等. 超声评估慢性肾衰竭患者自体动静脉内瘘成形术后并发症及预测其成熟的临床价值[J]. 临床超声医学杂志, 2024, 26(7):549-553.
	SHU Q P, ZHANG J, YIN N, et al. Clinical value of ultrasound in evaluating complications after autologous arteriovenous fistula and predicting its maturity in patients with chronic renal failure[J]. J Clin Ultras Med, 2024, 26(7):549-553. doi:10.3969/j.issn.1008-6978.2024.07.004.
[4]	吕彦辉, 陈建华, 张丽, 等. 降钙素原与维持性血液透析患者自体动静脉内瘘并发症的关系研究[J]. 天津医药, 2022, 50(4):413-417.
	LYU Y H, CHEN J H, ZHANG L, et al. The relationship between procalcitonin and complications of autogenous arteriovenous fistula in patients with maintenance hemodialysis[J]. Tianjin Med J, 2022, 50(4):413-417. doi:10.11958/20212097.
[5]	黄益彪, 吴俊男, 陆明晰. 超声引导下经皮紫杉醇涂层球囊腔内血管成形术治疗动静脉内瘘狭窄疗效初步探索[J]. 肾脏病与透析肾移植杂志, 2024, 33(4):333-338.
	HUANG Y B, WU J N, LU M X. Preliminary study on the curative effect of ultrasound guided paclitaxel-coated balloon dilation in patients with hemodialysis arteriovenous fistula stenosis[J]. Chin J Nephrol Dialys Transplant, 2024, 33(4):333-338. doi:10.3969/j.issn.1006-298X.2024.04.006.
[6]	刘大鹏, 任补元, 张佳佑, 等. 动静脉内瘘重建术与经皮球囊扩张术在老年自体动静脉内瘘狭窄患者中的临床应用[J]. 中华老年多器官疾病杂志, 2021, 20(12):885-888.
	LIU D P, REN B Y, ZHANG J Y, et al. Clinical application of arteriovenous fistula reconstruction and percutaneous transluminal angioplasty in elderly patients with stenosis of autogenous arteriovenous fistula[J]. Chin J Mult Organ Dis Elderly, 2021, 20(12):885-888. doi:10.11915/j.issn.1671-5403.2021.12.186.
[7]	陈立洲, 姚立正, 李文会, 等. 自体动静脉内瘘阻塞介入治疗疗效和术后通畅率影响因素分析[J]. 医学影像学杂志, 2022, 32(3):500-504.
	CHEN L Z, YAO L Z, LI W H, et al. Analysis of therapeutic effect and influencing factors of postoperative patency rate in the patients with autologous arteriovenous fistula obstruction treated with interventional therapy[J]. J Med Imag, 2022, 32(3):500-504. doi:10.3969/j.issn.1006-9011.2022.3.yxyxxzz202203038.
[8]	甘茂, 赵霞, 王哲, 等. 自体动静脉内瘘狭窄病变经皮腔内球囊扩张血管成形术后初级通畅时间的影响因素[J]. 血管与腔内血管外科杂志, 2023, 9(5):531-535.
	GAN M, ZHAO X, WANG Z, et al. Factors of primary patency time after percutaneous transluminal angioplasty in stenotic lesions of autogenous arteriovenous fistula[J]. J Vascul Endovascul Surg, 2023, 9(5):531-535. doi:10.19418/j.cnki.issn2096-0646.2023.05.04.
[9]	王志刚, 翟亚丽, 李玉倩, 等. 超声引导下球囊扩张术治疗自体动静脉内瘘狭窄的临床效果分析[J]. 生命科学仪器, 2022, 20(S1):41,43.
	WANG Z G, ZHAI Y L, LI Y Q, et al. Clinical effect analysis of ultrasound-guided balloon dilatation in the treatment of arteriovenous fistula stenosis[J]. Life Science Instruments, 2022, 20(S1):41,43. doi:10.11967/202200641.
[10]	GREGORY M, GUEST M, ABDEEN I, et al. Balloon assisted,ultrasound guided percutaneous thrombin injection of a large radial artery pseudoaneurysm using a trans-venous approach via an Ipsilateral Arteriovenous Fistula[J]. CVIR Endovasc, 2021, 4(1):67. doi:10.1186/s42155-021-00253-3.
[11]	中国医院协会血液净化中心分会血管通路工作组. 中国血液透析用血管通路专家共识(第2版)[J]. 中国血液净化, 2019, 18(6):365-381.
	Vascular Access Working Group of Blood Purification Center Branch of Chinese Hospital Association. Consensus among experts on blood access used for hemodialyis in China(The 2nd edition)[J]. Chin J Blood Purif, 2019, 18(6):365-381. doi:10.3969/j.issn.1671-4091.2019.06.001.
[12]	赵蕊, 张东亮, 贾建文, 等. 彩色多普勒超声评价血液透析患者自体动静脉内瘘的应用价值[J]. 中国超声医学杂志, 2017, 33(10):930-932.
	ZHAO R, ZHANG D L, JIA J W, et al. Application of color Doppler ultrasound for arteriovenous fistula in hemodialysis[J]. Chin J Ultra Med, 2017, 33(10):930-932. doi:10.3969/j.issn.1002-0101.2017.10.022.
[13]	宿敬存, 夏化文, 王海洋, 等. 经静脉途径介入治疗自体动静脉内瘘狭窄的临床效果及并发症防治分析[J]. 中国综合临床, 2020, 36(5):431-434.
	SU J C, XIA H W, WANG H Y, et al. Analysis of clinical effect and complication prevention and treatment of autogenous arteriovenous fistulas stenosis by intravenous intervention therapy[J]. Clin Med Chin, 2020, 36(5):431-434. doi:10.3760/cma.j.cn121361-20200509-00050.
[14]	VAZQUEZ-PADRON R I, DUQUE J C, TABBARA M, et al. Intimal hyperplasia and arteriovenous fistula failure:looking beyond size differences[J]. Kidney, 360, 2021, 2(8):1360-1372. doi:10.34067/KID.0002022021.
[15]	王蕊, 朱莉敏, 李静, 等. 超声引导下动静脉内瘘球囊扩张术在维持性血液透析动静脉内瘘血管狭窄中的应用[J]. 医学影像学杂志, 2020, 30(10):1898-1901.
	WANG R, ZHU L M, LI J, et al. Application of ultrasound-guided arteriovenous balloon angioplasty in maintenance of hemorrhagic arteriovenous fistula stenosis[J]. J Med Imag, 2020, 30(10):1898-1901.
[16]	丁常春. 超声引导下经皮球囊扩张对动静脉内瘘狭窄患者血管狭窄程度、最大透析流量和术后舒适度的影响[J]. 临床误诊误治, 2023, 36(9):108-111.
	DING C C. Effect of ultrasound-guided percutaneous balloon dilation on the degree of vascular stenosis,maximum dialysis flow and postoperative comfort in patients with arteriovenous fistula stenosis[J]. Clin Misdiagn Misther, 2023, 36(9):108-111. doi:10.3969/j.issn.1002-3429.2023.09.022.
[17]	BURNETT C T, NICHOLLS G, SWINBANK A, et al. Cephalic arch stenosis in the arteriovenous fistula:a retrospective analysis of predisposing factors[J]. J Vasc Access, 2023, 24(5):1084-1090. doi:10.1177/11297298211067848.
[18]	王清. 超声引导下经皮球囊扩张术应用于血管通路狭窄治疗的效果观察[J]. 中国血液净化, 2023, 22(9):698-700,714.
	WANG Q. Ultrasound guided percutaneous balloon dilatation applied to the treatment of vascular access stenosis[J]. Chin J Blood Purif, 2023, 22(9):698-700,714. doi:10.3969/j.issn.1671-4091.2023.09.014.
[19]	卢松芳, 陈靖, 马鹏跃, 等. 超声引导下二次经皮腔内血管成形术治疗动静脉内瘘术后再狭窄效果观察[J]. 山东医药, 2020, 60(20):55-57.
	LU S F, CHEN J, MA P Y, et al. Effect of ultrasound-guided secondary percutaneous transluminal angioplasty in the treatment of restenosis after arteriovenous fistula[J]. Shandong Med J, 2020, 60(20):55-57. doi:10.3969/j.issn.1002-266X.2020.20.014.

组别		n	年龄/岁	性别（男/女）		透析时间/周
DSA组		38	57.89±4.51	18/20		18.20±6.69
超声引导组		40	57.48±3.98	22/18		17.80±5.28
t或χ²			0.436	0.454		0.296
组别	病程/周		原发疾病
组别	病程/周		高血压肾病	糖尿病肾病	慢性肾炎	其他
DSA组	3.12±0.70		14	14	9	1
超声引导组	3.31±0.54		13	17	8	2
t或χ²	1.343		1.033

组别		n	年龄/岁	性别（男/女）		透析时间/周
DSA组		38	57.89±4.51	18/20		18.20±6.69
超声引导组		40	57.48±3.98	22/18		17.80±5.28
t或χ²			0.436	0.454		0.296
组别	病程/周		原发疾病
组别	病程/周		高血压肾病	糖尿病肾病	慢性肾炎	其他
DSA组	3.12±0.70		14	14	9	1
超声引导组	3.31±0.54		13	17	8	2
t或χ²	1.343		1.033

组别	n	一次穿刺成功	手术用时/min	术中出血量/mL	术后内瘘开始使用时间/d
DSA组	38	32（84.21）	68.47±13.91	15.03±2.08	1.84±0.19
超声引导组	40	39（97.50）	62.10±13.06	14.18±2.08	1.79±0.15
t或χ²		4.213^＊	2.088^＊	1.813	1.306

组别	n	一次穿刺成功	手术用时/min	术中出血量/mL	术后内瘘开始使用时间/d
DSA组	38	32（84.21）	68.47±13.91	15.03±2.08	1.84±0.19
超声引导组	40	39（97.50）	62.10±13.06	14.18±2.08	1.79±0.15
t或χ²		4.213^＊	2.088^＊	1.813	1.306

组别		n		内径大小/mm
组别		n		术前				术后7 d		t
DSA组		38		1.29±0.17				3.03±0.22		49.664^＊
超声引导组		40		1.27±0.10				3.25±0.35		34.532^＊
t				0.510				3.300^＊
组别	透析血流量/（mL/min）
组别	术前						术后7 d				t
DSA组	160.38±7.57						251.06±10.02				44.617^＊
超声引导组	159.74±8.51						257.85±8.88				53.120^＊
t	0.348						3.170^＊
组别	内瘘自然血流量/（mL/min）
组别	术前						术后7 d				t
DSA组	287.48±10.68						472.19±24.02				47.848^＊
超声引导组	284.51±12.81						489.73±30.69				45.059^＊
t	1.108						2.802^＊
组别			横截面积/mm²
组别			术前		术后7 d				t
DSA组			3.00±0.84			14.71±4.64			15.881^＊
超声引导组			3.10±0.54			14.68±4.72			15.483^＊
t			0.701			0.032
