Effects of polymer assisted deposition of Ta2O5 coating on the surface of TiO2 nanotubes on improving the biological activity of MC3T3-E1 cells

doi:10.11958/20230648

Abstract

Abstract:

Objective To explore the effect of polymer assisted deposition of tantalum pentoxide (Ta₂O₅) coating on the surface of TiO₂ nanotubes on the biological activity of mouse bone forming precursor cells, MC3T3-E1 cells. Methods Three sets of samples were prepared, including Ta/TiO₂nanotubes (the Ta/NT group), Ta₂O₅/pure titanium (the Ta₂O₅/PT group) and Ta₂O₅/ TiO₂ nanotubes (the Ta₂O₅/NT group). The Ta₂O₅/PT group and the Ta₂O₅/NT group were prepared by polymer-assisted deposition. The three sets of samples were characterized and tested by scanning electron microscopy (SEM) to observe the surface morphology. X-ray photoelectron spectroscopy (XPS) was used to analyze surface element composition, and X-ray diffraction (XRD) was used to detect surface compounds. MC3T3-E1 cells were selected to explore the effect of three groups of samples on cell biological activity. Fluorescence microscope was used to observe the adhesion of cytoskeleton and nucleus. Cell activity was determined by CCK-8 method. Cell alkaline phosphatase (ALP) activity was detected. Calcium deposition was detected by alizarin red staining and semi-quantitative analysis. The expression levels of recombinant human bone morphogenetic protein-2 (BMP-2), ALP, osteocalcin (OCN) and osteopontin (OPN) were detected by real-time PCR. Results SEM images showed that on the surface of the Ta₂O₅/NT group, the TiO₂ nanotube substrate was covered with a sheet-like, banded cross-linked micro-nano Ta₂O₅ coating structure. XRD showed that the TiO₂ nanotubes in the Ta₂O₅/NT group presented a trace of demineralized titanium and rutile crystal structure. Compared with the Ta/NT group, the Ta₂O₅/NT group and the Ta₂O₅/PT group showed higher cell density, larger cytoskeletal mass and filamentous structure, more crosslinking and clusters, higher cytoskeletal tension and higher cell activity. The semi-quantitative analysis of alizarin red staining samples showed that calcium deposition decreased successively in the Ta₂O₅/NT group, the Ta/NT group and the Ta₂O₅/PT group (P<0.01). The ALP activity, calcium deposition and ALP, OCN and OPN mRNA contents on day 7 and 14 were decreased successively in the Ta₂O₅/NT group, the Ta/NT group and the Ta₂O₅/PT group, and the BMP-2 mRNA content on day 14 in the Ta₂O₅/NT group was the highest in the three groups (P<0.05). Conclusion Ta₂O₅/TiO₂ nanotube composite coating can promote the adhesion of MC3T3-E1 cells, the expression of mineralization and osteogenic genes, and enhance the activities of cell and ALP, which is conducive to the play of biological activities.

Key words: Titanium, nanotubes, Tantalum, Tantalum pentoxide coating, polymer-assisted deposition, surface characterization, biological activity

CLC Number:

R783.1

Figures/Tables 7

References 21

[1]	KHRUNYK Y Y, BELIKOV S V, TSURKAN M V, et al. Surface-dependent osteoblasts response to TiO₂ nanotubes of different crystallinity[J]. Nanomaterials(Basel), 2020, 10(2):320. doi:10.3390/nano10020320.
[2]	OCAMPO R A, ECHEVERRIA F E. Antibacterial and biological behavior of TiO₂ nanotubes produced by anodizing technique[J]. Crit Rev Biomed Eng, 2021, 49(1):51-65. doi:10.1615/CritRevBiomedEng.2021037758.
[3]	PARK J, CIMPEAN A, TESLER A B, et al. Anodic TiO₂ nanotubes:tailoring osteoinduction via drug delivery[J]. Nanomaterials(Basel), 2021, 11(9):2359. doi:10.3390/nano11092359.
[4]	HASHEMI A, EZATI M, MOHAMMADNEJAD J, et al. Chitosan coating of TiO₂ nanotube arrays for improved metformin release and osteoblast differentiation[J]. Int J Nanomedicine, 2020, 15:4471-4481. doi:10.2147/IJN.S248927.
[5]	韩天啸, 句世颖, 何琳, 等. 载锶纳米管化纯钛种植体成骨性能的动物实验[J]. 中华口腔医学杂志, 2022, 57(6):618-624.
	HAN T X, JU S Y, HE L, et al. In vivo osteogenic evaluation of titanium implants with strontium loaded nanotubes[J]. Chinese Journal of Stomatology, 2022, 57(6):618-624. doi:10.3760/cma.j.cn112144-20211019-00469.
[6]	TANG J, LI H, GUO M, et al. Enhanced spreading,migration and osteodifferentiation of HBMSCs on macroporous CS-Ta - A biocompatible macroporous coating for hard tissue repair[J]. Mater Sci Eng C Mater Biol Appl, 2021, 129:112411. doi:10.1016/j.msec.2021.112411.
[7]	LEI P, QIAN H, ZHANG T, et al. Porous tantalum structure integrated on Ti₆Al₄V base by laser powder bed fusion for enhanced bony-ingrowth implants:in vitro and in vivo validation[J]. Bioact Mater, 2022, 7:3-13. doi:10.1016/j.bioactmat.2021.05.025.
[8]	HUANG G, PAN S T, QIU J X. The clinical application of porous tantalum and its new development for bone tissue engineering[J]. Materials(Basel), 2021, 14(10):2647. doi:10.3390/ma14102647.
[9]	ASADULLAH S, MEI S, WANG D, et al. Sulfonated porous surface of tantalum pentoxide/polyimide composite with micro-submicro structures displaying antibacterial performances and stimulating cell responses[J]. Materials & Design, 2020, 190:108510. doi:10.1016/j.matdes.2020.108510.
[10]	SARRAF M, RAZAK B A, NASIRI-TABRIZI B, et al. Nanomechanical properties,wear resistance and in-vitro characterization of Ta₂O₅ nanotubes coating on biomedical grade Ti-₆Al-₄V[J]. J Mech Behav Biomed Mater, 2017, 66:159-171. doi:10.1016/j.jmbbm.2016.11.012.
[11]	PANG Z, PAN Z, MA M, et al. Nanostructured coating of non-crystalline tantalum pentoxide on polyetheretherketone enhances RBMS cells/HGE cells adhesion[J]. Int J Nanomedicine, 2021, 16:725-740. doi:10.2147/IJN.S286643.
[12]	XU G, SHEN X, HU Y, et al. Fabrication of tantalum oxide layers onto titanium substrates for improved corrosion resistance and cytocompatibility[J]. Surf Coat Tech, 2015, 272:58-65. doi:10.1016/j.surfcoat.2015.04.024.
[13]	WANG F, LI C, ZHANG S, et al. Tantalum coated on titanium dioxide nanotubes by plasma spraying enhances cytocompatibility for dental implants[J]. Surf Coat Tech, 2020, 382:125161. doi:10.1016/j.surfcoat.2019.125161.
[14]	SOUZA J, SORDI M B, KANAZAWA M, et al. Nano-scale modification of titanium implant surfaces to enhance osseointegration[J]. Acta Biomater, 2019, 94:112-131. doi:10.1016/j.actbio.2019.05.045.
[15]	LI J, HOU W, YANG Y, et al. Micro/nano-topography promotes osteogenic differentiation of bone marrow stem cells by regulating periostin expression[J]. Colloids Surf B Biointerfaces, 2022, 218:112700. doi:10.1016/j.colsurfb.2022.112700.
[16]	HOU C, AN J, ZHAO D, et al. Surface modification techniques to produce micro/nano-scale topographies on Ti-based implant surfaces for improved osseointegration[J]. Front Bioeng Biotechnol, 2022, 10:835008. doi:10.3389/fbioe.2022.835008.
[17]	BENČINA M, IGLIČ A, MOZETIČ M, et al. Crystallized TiO₂ nanosurfaces in biomedical applications[J]. Nanomaterials(Basel), 2020, 10(6):1121. doi:10.3390/nano10061121.
[18]	KIM S Y, KIM Y K, PARK I S, et al. Effect of alkali and heat treatments for bioactivity of TiO₂ nanotubes[J]. Applied Surface Science, 2014, 321:412-419. doi:10.1016/j.apsusc.2014.09.177.
[19]	EPIFANI M, ZAMANI R, ARBIOL J, et al. Soft chemistry routes to transparent metal oxide thin films. The case of sol-gel synthesis and structural characterization of Ta₂O₅ thin films from tantalum chloromethoxide[J]. Thin Solid Films, 2014, 555:39-41. doi:10.1016/j.tsf.2013.05.139.
[20]	GUI N, XU W, MYERS D E, et al. The effect of ordered and partially ordered surface topography on bone cell responses:a review[J]. Biomater Sci, 2018, 6(2):250-264. doi:10.1039/c7bm01016h.
[21]	NOURI-GOUSHKI M, ANGELONI L, MODARESIFAR K, et al. 3D-printed submicron patterns reveal the interrelation between cell adhesion,cell mechanics,and osteogenesis[J]. ACS Appl Mater Interfaces, 2021, 13(29):33767-33781. doi:10.1021/acsami.1c03687.

组别	1 d	4 d	7 d
Ta/NT组	0.267±0.015	0.403±0.021	0.633±0.015
Ta₂O₅/PT组	0.307±0.015^a	0.493±0.015^a	0.873±0.021^a
Ta₂O₅/NT组	0.330±0.020^a	0.487±0.015^a	0.860±0.017^a
F	10.654^＊	235.148^＊＊	169.379^＊＊

组别	1 d	4 d	7 d
Ta/NT组	0.267±0.015	0.403±0.021	0.633±0.015
Ta₂O₅/PT组	0.307±0.015^a	0.493±0.015^a	0.873±0.021^a
Ta₂O₅/NT组	0.330±0.020^a	0.487±0.015^a	0.860±0.017^a
F	10.654^＊	235.148^＊＊	169.379^＊＊

组别	7 d	14 d
Ta/NT组	2.993±0.051	2.420±0.072
Ta₂O₅/PT组	2.577±0.132^a	2.133±0.112^a
Ta₂O₅/NT组	3.197±0.083^ab	2.677±0.112^ab
F	33.298^＊＊	21.968^＊＊

组别	7 d	14 d
Ta/NT组	2.993±0.051	2.420±0.072
Ta₂O₅/PT组	2.577±0.132^a	2.133±0.112^a
Ta₂O₅/NT组	3.197±0.083^ab	2.677±0.112^ab
F	33.298^＊＊	21.968^＊＊

组别	ALP		OCN		OPN		BMP-2
组别	7 d	14 d	7 d	14 d	7 d	14 d	7 d	14 d
Ta/NT组	2.326±0.114	3.015±0.210	2.696±0.116	8.307±0.396	1.978±0.082	0.699±0.020	2.089±0.241	5.570±0.692
Ta₂O₅/PT组	1.690±0.108^a	2.590±0.154^a	0.840±0.070^a	1.013±0.121^a	1.003±0.106^a	0.553±0.078^a	0.913±0.060^a	4.353±0.235^a
Ta₂O₅/NT组	2.563±0.091^ab	3.727±0.078^ab	3.063±0.138^ab	10.283±0.286^ab	2.433±0.120^ab	0.810±0.044^ab	1.670±0.111^ab	6.727±0.250^ab
F	55.895^＊＊	40.233^＊＊	324.817^＊＊	847.407^＊＊	148.039^＊＊	17.871^＊＊	43.111^＊＊	21.236^＊＊

Effects of polymer assisted deposition of Ta₂O₅ coating on the surface of TiO₂ nanotubes on improving the biological activity of MC3T3-E1 cells

Cite this article

RichHTML

PDF (PC)

Knowledge

Abstract

share this article

Figures/Tables 7

References 21

Related Articles 12

Recommended Articles

Metrics

Comments

基因名称	引物序列（5′→3′）	产物大小（bp）
BMP-2	上游：TGTGGACTTCAGTGATGTG	59
BMP-2	下游：TGGAGTTCAGGTGGTCAG	59
OCN	上游：TTCTGCTCACTCTGCTGACC	43
OCN	下游：GCCGGAGTCTGTTCACTACC	43
ALP	上游：GGCTACTTCTTCGTGGAG	82
ALP	下游：GCGTGAGTGTTCTTGTCT	82
OPN	上游：GCTTGGCTTATGGACTGA	65
OPN	下游：TAGACTCACCGCTCTTCA	65
GAPDH	上游：AGAAGGTGGTGAAGCAGGCATCT	125
GAPDH	下游：CGGCATCGAAGGTGGAAGAGTG	125
