Application effect of percutaneous vertebroplasty combined with 3D-printed personalized vertebral body stents in the repair of thoracolumbar vertebral fractures

doi:10.11958/20251037

Abstract

Abstract:

Objective To explore the application effect of vertebroplasty (PVP) combined with precise personalized vertebral stent implantation based on 3D biomechanical modeling in the repair of thoracolumbar fractures. Methods A total of 98 patients with thoracolumbar vertebral fractures treated at our hospital from September 2021 to December 2022 were selected for this study. Patients were divided into two groups based on the surgical method: the conventional group (n=50) and the combined group (n=48). The conventional group received PVP treatment, while the combined group was treated with PVP combined with 3D-printed personalized vertebral body stents. The length of incision, operation time, blood loss, drainage volume and hospital stay of the two groups were recorded. The Oswestry Disability Index (ODI) was used to assess the improvement of thoracolumbar function in patients before surgery and one month after the surgery. Cobb angle, anterior height of injured vertebra and sagittal position index were measured. Visual Analog Scale (VAS) for pain and Short Form-36 (SF-36) questionnaire for quality of life were used to evaluate low back pain, lower extremity pain and quality of life of patients before surgery and one month after surgery. Postoperative complications were also recorded. Results The length of incision, operation time, blood loss, drainage volume and hospital stay were lower in the combination group than those of the conventional group (P<0.05). ODI score and Cobb angle were lower 1 month after surgery than those before surgery in both groups, and the combined group was lower than the conventional group (P<0.05). One month after operation, the anterior height and sagittal position index of injured vertebrae were higher than those before surgery, and the combined group was higher than the conventional group (P<0.05). VAS scores were lower and SF-36 scores were higher in both groups one month after operation compared to those before the operation, with the combined group showing lower VAS scores and higher SF-36 scores compared to the conventional group (P<0.05). The total complication rate was lower in the combined group (2.08%) than that in the conventional group (16.00%, P<0.05). There was no significant difference in the overall postoperative satisfaction between the conventional group and the combined group. Conclusion The treatment of thoracolumbar fractures with PVP combined with 3D printed personalized vertebral stenting has a remarkable effect. The pain and quality of life of patients have been significantly improved, and the surgical safety is relatively good.

Key words: fractures, vertebral body, percutaneous vertebro plasty, biomechanics, 3D printing, cement leakage

CLC Number:

R274.1

Figures/Tables 6

References 24

[1]	TANASANSOMBOON T, KITTIPIBUL T, LIMTHONGKUL W, et al. Thoracolumbar burst fracture without neurological deficit:review of controversies and current evidence of treatment[J]. World Neurosurg,  2022,162:29-35. doi:10.1016/j.wneu.2022.03.061.
[2]	GAVIRA N, AMELOT A, COOK A R, et al. Thoracolumbar spinal fracture in children:conservative or surgical treatment?[J]. Neurochirurgie, 2022, 68(3):309-314. doi:10.1016/j.neuchi.2021.06.014.
[3]	LI C, LAI X M, LIU N, et al. Correlation analysis of the vertebral compression degree and CT HU value in elderly patients with osteoporotic thoracolumbar fractures[J]. J Orthop Surg Res, 2023, 18(1):457. doi:10.1186/s13018-023-03941-z.
[4]	HAIBIER A, JIE Y, YUSUFU A, et al. Effect of different cement distribution on the clinical efficacy of vertebral compression fractures in unilateral percutaneous vertebroplasty[J]. Eur Spine J, 2025(1): 13. doi:10.1007/s00586-024-08630-x.
[5]	张迦琅, 李庆达, 贺园, 等. 局部强化与常规麻醉下经皮椎体成形术治疗多节段急性症状性骨质疏松性胸腰椎骨折的疗效比较[J]. 中华创伤杂志, 2024, 40(5):432-439.
	ZHANG J L, LI Q D, HE Y, et al. Comparison of efficacy between local reinforcement and general anesthesia percutaneous vertebroplasty for multilevel acute symptomatic osteoporotic thoracolumbar fractures[J]. Chinese Journal of Trauma, 2024, 40(5):432-439. doi:10.3760/cma.j.cn501098-20240226-00164.
[6]	钱黎, 王大寿, 潘奇, 等. 唑来膦酸预防骨质疏松性椎体压缩性骨折术后椎体再发骨折的疗效分析[J]. 天津医药, 2023, 51(11):1258-1261.
	QIAN L, WANG D S, PAN Q, et al. Efficacy analysis of zoledronic acid in preventing recurrent vertebral fractures after osteoporotic vertebral compression fracture surgery[J]. Tianjin Med J, 2023, 51(11):1258-1261. doi:10.11958/20220262.
[7]	张鹏贵, 李延红. 椎弓根螺钉内固定结合经皮椎体成形术治疗骨质疏松性胸腰椎骨折的临床效果与术后再骨折的影响研究[J]. 贵州医药, 2020, 44(10):1598-1600.
	ZHANG P G, LI Y H. Clinical efficacy and effect on postoperative refracture of pedicle screw internal fixation combined with percutaneous vertebroplasty for osteoporotic thoracolumbar fractures[J]. Guizhou Med J, 2020, 44(10):1598-1600. doi:10.3969/j.issn.1000-744X.2020.10.043.
[8]	张斌, 蒲昊, 王明忠, 等. 后路椎弓根内固定术联合椎体成形术治疗胸腰椎骨折患者的效果[J]. 实用临床医药杂志, 2020, 24(20):15-17,21.
	ZHANG B, PU H, WANG M Z, et al. Effect of posterior pedicle screw fixation combined with vertebroplasty on patients with thoracolumbar fractures[J]. Pract Clin Med J, 2020, 24(20):15-17,21. doi:10.7619/jcmp.202020004.
[9]	YUAN X, ZHU W, YANG Z, e al. Recent advances in 3D printing of smart scaffolds for bone tissue engineering and regeneration[J]. Adv Mater, 2024, 36(34):e2403641. doi:10.1002/adma.202403641.
[10]	XU J, JI J, JIAO J, et al. 3D printing for bone-cartilage interface regeneration[J]. Front Bioeng Biotechnol, 2022,10:828921. doi:10.3389/fbioe.2022.828921.
[11]	眭涛, 陈建, 黄振飞, 等. 老年骨质疏松性胸腰椎骨折后脊柱重建临床指南(2022版)[J]. 中华创伤杂志, 2022, 38(12):1057-1066.
	SUI T, CHEN J, HUANG Z F, et al. Clinical guidelines for spinal reconstruction after osteoporotic thoracolumbar fractures in elderly (2022 edition)[J]. Chinese Journal of Trauma, 2022, 38(12):1057-1066. doi:10.3760/cma.j.cn501098-20220912-00605.
[12]	CHIAROTTO A, MAXWELL L J, TERWEE C B, et al. Roland-morris disability questionnaire and oswestry disability index:which has better measurement properties for measuring physical functioning in nonspecific low back pain? systematic review and Meta-analysis[J]. Phys Ther, 2016, 96(10):1620-1637. doi:10.2522/ptj.20150420.
[13]	SUNG Y T, WU J S. The visual analogue scale for rating,ranking and paired-comparison(VAS-RRP):a new technique for psychological measurement[J]. Behav Res Methods, 2018, 50(4):1694-1715. doi:10.3758/s13428-018-1041-8.
[14]	LV X L, JIANG Y H, SUN Y H, et al. Short form 36 - item health survey test result on the empty nest elderly in china:a meta-analysis[J]. Arch Gerontol Geriatr, 2013, 56(2):291-297. doi:10.1016/j.archger.2012.10.011.
[15]	刘相英, 刘建军, 明新堂. 浸骨水泥明胶海绵填充在经皮椎体成形术治疗老年胸腰椎骨折中的应用[J]. 临床骨科杂志, 2022, 25(5):619-622.
	LIU X Y, LIU J J, MING X T. Application of bone cement gelatin sponge filling in percutaneous vertebroplasty for elderly thoracolumbar fractures[J]. Clin Orthop J, 2022, 25(5):619-622. doi:10.3969/j.issn.1008-0287.2022.05.004.
[16]	高超, 郁春, 管礼安, 等. 骨质疏松性胸腰椎骨折经皮椎体成形术后骨水泥分布类型对疗效的影响[J]. 中国医药导报, 2023, 20(3):84-87.
	GAO C, YU C, GUAN L A, et al. Influence of bone cement distribution patterns on efficacy after percutaneous vertebroplasty for osteoporotic thoracolumbar fractures[J]. China Med Herald, 2023, 20(3):84-87. doi:10.20047/j.issn1673-7210.2023.03.19.
[17]	MENG M, WANG J, HUANG H, et al. 3D printing metal implants in orthopedic surgery:methods,applications and future prospects[J]. J Orthop Translat, 2023, 42:94-112. doi:10.1016/j.jot.2023.08.004.
[18]	MACDONALD A F, HARLEY-TROXELL M E, NEWBY S D, et al. 3D -printing graphene scaffolds for bone tissue engineering[J]. Pharmaceutics, 2022, 14(9):1834. doi:10.3390/pharmaceutics14091834.
[19]	曾柏方, 吴超, 李涛, 等. 3D打印皮外导板辅助微创椎弓根螺钉植入治疗多节段胸腰椎骨折[J]. 中国修复重建外科杂志, 2021, 35(6):742-749.
	ZENG B F, WU C, LI T, et al. 3D printed external guide plate-assisted minimally invasive pedicle screw implantation for multilevel thoracolumbar fractures[J]. Chin J Repar Reconstr Surg, 2021, 35(6):742-749. doi:10.7507/1002-1892.202012081.
[20]	YANG F, LIU Z, LI P, et al. Analysis of potential risk factors for cement leakage into paraspinal veins after vertebroplasty for acute osteoporotic vertebral fractures based on a 3D reconstruction technique:a retrospective matched case-control study[J]. Orthop Surg, 2023, 15(12):3209-3222. doi:10.1111/os.13924.
[21]	LIN X, XIAO X, WANG Y, e al. Biocompatibility of bespoke 3D-printed titanium alloy plates for treating acetabular fractures[J]. Biomed Res Int, 2018,2018:2053486. doi:10.1155/2018/2053486.
[22]	PHANINDRA BOGU V, RAVI KUMAR Y, KUMAR KHANRA A. Homogenous scaffold-based cranial/skull implant modelling and structural analysis-unit cell algorithm - meshless approach[J]. Med Biol Eng Comput, 2017, 55(11):2053-2065. doi:10.1007/s11517-017-1649-3.
[23]	WARBURTON A, GIRDLER S J, MIKHAIL C M, et al. Biomaterials in spinal implants:a review[J]. Neurospine, 2020, 17(1):101-110. doi:10.14245/ns.1938296.148.
[24]	姜江. 3D打印个体化导板辅助治疗无神经损伤胸腰椎骨折效果[J]. 现代科学仪器, 2022, 39(3):179-183.
	JIANG J. Effect of 3D printed individualized guide plate-assisted treatment of thoracolumbar fractures without neurological injury[J]. Modern Sci Instrum, 2022, 39(3):179-183.

组别		n	年龄/岁			性别
组别		n	年龄/岁			男		女
常规组		50	52.64±4.62			28（56.0）		22（44.0）
联合组		48	53.04±4.86			30（62.5）		18（37.5）
t或χ²			0.419			0.428
组别	骨折部位
组别	T₁₁			T₁₂	L₁		L₂		L₃
常规组	8（16.0）			10（20.0）	12（24.0）		13（26.0）		7（14.0）
联合组	9（18.7）			8（16.7）	13（27.1）		10（20.8）		8（16.7）
χ²	0.739

组别		n	年龄/岁			性别
组别		n	年龄/岁			男		女
常规组		50	52.64±4.62			28（56.0）		22（44.0）
联合组		48	53.04±4.86			30（62.5）		18（37.5）
t或χ²			0.419			0.428
组别	骨折部位
组别	T₁₁			T₁₂	L₁		L₂		L₃
常规组	8（16.0）			10（20.0）	12（24.0）		13（26.0）		7（14.0）
联合组	9（18.7）			8（16.7）	13（27.1）		10（20.8）		8（16.7）
χ²	0.739

组别	n	切口长度/cm	手术时间/min
常规组	50	11.08±1.25	35.94±4.80
联合组	48	10.46±0.82	30.24±4.35
t		2.879＊	6.142＊＊
组别	术中出血量/mL	术后引流量/mL	住院时间/d
常规组	32.64±3.78	25.30±4.14	5.38±0.88
联合组	26.48±3.06	23.63±3.85	4.46±0.62
t	8.849^＊＊	2.074^＊	6.002^＊＊

组别	n	切口长度/cm	手术时间/min
常规组	50	11.08±1.25	35.94±4.80
联合组	48	10.46±0.82	30.24±4.35
t		2.879＊	6.142＊＊
组别	术中出血量/mL	术后引流量/mL	住院时间/d
常规组	32.64±3.78	25.30±4.14	5.38±0.88
联合组	26.48±3.06	23.63±3.85	4.46±0.62
t	8.849^＊＊	2.074^＊	6.002^＊＊

组别	n		ODI/分
组别	n		术前		术后1个月		t
常规组	50		60.46±9.32		18.36±2.89		28.520^＊＊
联合组	48		61.04±9.31		12.50±1.81		34.501^＊＊
t			0.309		11.969^＊＊
组别		Cobb角/°
组别		术前		术后1个月		t
常规组		17.44±2.48		7.14±0.67		27.548^＊＊
联合组		16.94±2.60		5.48±0.50		29.094^＊＊
t		0.958		13.811^＊＊
组别		伤椎前缘高度/%
组别		术前		术后1个月		t
常规组		66.48±10.21		85.27±10.08		9.086^＊＊
联合组		67.34±9.81		89.55±8.26		12.099^＊＊
t		0.425		2.288^＊
组别		矢状面指数/%
组别		术前		术后1个月		t
常规组		62.54±4.95		79.24±9.30		10.565^＊＊
联合组		62.87±6.06		83.66±9.64		14.139^＊＊
t		0.296		2.312^＊
