Predictive value of vertebral CT parameters for early fusion sink after TLIF

doi:10.11958/20241833

Abstract

Abstract:

Objective To investigate the prognostic value of vertebral CT parameters for early fusion sink after transforaminal lumbar interbody fusion (TLIF). Methods The clinical and imaging data of 178 patients with lumbar degenerative diseases treated by TLIF were retrospectively studied. The patients were divided into the sedimentation group (n=57) and the non-sedimentation (n=57) group according to the patient's fusion device settlement 3 months after surgery. The results of general data and CT image parameters were compared between the two groups. Multivariate Logistic regression was used to analyze risk factors of early fusion subsidence, and the prediction efficiency was analyzed. Results The incidence of the early fusion sink was 32.0%. Compared with the non-sedimentation group, the sedimentation group had a higher proportion of patients aged ≥60 years, osteoporosis, L5-S1 and intervertebral space height, larger fusion contact area and segmental lordosis angle and lower lumbar CT value (P<0.05). Logistic regression analysis showed that age ≥60 years old, surgical level L₅-S₁, high intervertebral height and large segmental lordosis angle were independent risk factors for the early fusion after TLIF, while high lumbar CT value was protective factor (P<0.05). Subject working characteristic curves showed that the area under the curve (AUC) of lumbar CT value, intervertebral height, segmental lordosis angle combined with AUC were higher than those of patients aged ≥60 years, surgical segment L₅-S₁, lumbar CT value, intervertebral height, segmental lordosis angle applied alone (P<0.05). Conclusion Vertebral CT parameters of lumbar CT value, intervertebral height and segmental lordosis angle have higher predictive value for the early fusion after TLIF, and the combined prediction value of the three parameters is higher.

Key words: intervertebral disc degeneration, vertebral body, tomography, X-ray computed, transforaminal lumbar interbody fusion, cage subsidence

CLC Number:

R681.5

Figures/Tables 7

References 23

[1]	HEO D H, KIM J Y, PARK J Y, et al. Clinical experiences of 3-dimensional biportal endoscopic spine surgery for lumbar degenerative disease[J]. Oper Neurosurg(Hagerstown), 2022, 22(4):231-238. doi:10.1227/ONS.0000000000000090.
[2]	MACKI M, HAMILTON T, HADDAD Y W, et al. Expandable cage technology-transforaminal,anterior,and lateral lumbar interbody fusion[J]. Oper Neurosurg(Hagerstown), 2021, 21(Suppl 1):S69-S80. doi:10.1093/ons/opaa342.
[3]	GODOLIAS P, TATARYN Z L, PLÜMER J, et al. Cage subsidence-a multifactorial matter![J]. Orthopadie (Heidelb), 2023, 52(8):662-669. doi:10.1007/s00132-023-04363-9.
[4]	ROBERTSON T S, PIJLS B G, MUNN Z, et al. Change in CT-measured acetabular bone density following total hip arthroplasty:a systematic review and meta-analysis[J]. Acta Orthop, 2023,94:191-199. doi:10.2340/17453674.2023.11635.
[5]	PU X, WANG D, GU S. Advances in Hounsfield units value for predicting cage subsidence on spinal interbody fusion surgery[J]. Eur Spine J, 2023, 32(9):3149-3157. doi:10.1007/s00586-023-07805-2.
[6]	范宇澄, 蔡东岭, 郭伟俊, 等. 腰椎终板形态对经椎间孔腰椎椎间融合术后融合器沉降的影响[J]. 实用骨科杂志, 2023, 29(3):193-197,213.
	FAN Y C, CAI D L, GUO W J, et al. Effect of lumbar endplate morphology on cage subsidence after transforaminal lumbar interbody fusion[J]. Journal of Practical Orthopedics, 2023, 29(3):193-197,213.
[7]	DHAR U K, MENZER E L, LIN M, et al. Factors influencing cage subsidence in anterior cervical corpectomy and discectomy:a systematic review[J]. Eur Spine J, 2023, 32(3):957-968. doi:10.1007/s00586-023-07530-w.
[8]	MARCHI L, ABDALA N, OLIVEIRA L, et al. Radiographic and clinical evaluation of cage subsidence after stand-alone lateral interbody fusion[J]. J Neurosurg Spine, 2013, 19(1):110-118. doi:10.3171/2013.4.SPINE12319.
[9]	WANG L, LI H, ZHAO Y, et al. Ligamentum-preserved/temporary preserved minimally invasive transforaminal lumbar interbody fusion for lumbar spondylolisthesis:technical note and 2-year follow-up[J]. Spine(Phila Pa 1976), 2022, 47(8):E328-E336. doi:10.1097/BRS.0000000000004136.
[10]	SEBAALY A, KREICHATI G, TARCHICHI J, et al. Transforaminal lumbar interbody fusion using banana-shaped and straight cages:meta-analysis of clinical and radiological outcomes[J]. Eur Spine J, 2023, 32(9):3158-3166. doi:10.1007/s00586-023-07797-z.
[11]	李根, 李鑫, 杨硕, 等. 经椎间孔腰椎椎间融合术术后融合器沉降预测模型的建立与验证[J]. 医学研究杂志, 2023, 52(5):55-61.
	LI G, LI X, YANG S, et al. Development and validation of a predictive model for cage subsidence after transforaminal lumbar interbody fusion[J]. Journal of Medical Research, 2023, 52(5):55-61. doi:10.11969/j.issn.1673-548X.2023.05.013.
[12]	SUN W X, LIU H N, CHEN M T, et al. Meta-analysis of the clinical efficacy and safety of oblique lateral interbody fusion and transforaminal interbody fusion in the treatment of degenerative lumbar spondylolisthesis[J]. EFORT Open Rev, 2022, 7(9):663-670. doi:10.1530/EOR-22-0042.
[13]	金锋, 王焕, 唐世技, 等. TLIF术后融合器下沉的危险因素调查[J]. 颈腰痛杂志, 2023, 44(4):663-665.
	JIN F, WANG H, TANG S J, et al. Investigation on the risk factors of fusion apparatus sinking after TLIF operation[J]. The Journal of Cervicodynia and Lumbodynia, 2023, 44(4):663-665. doi:10.3969/j.issn.1005-7234.2023.04.046.
[14]	AMORIM-BARBOSA T, PEREIRA C, CATELAS D, et al. Risk factors for cage subsidence and clinical outcomes after transforaminal and posterior lumbar interbody fusion[J]. Eur J Orthop Surg Traumatol, 2022, 32(7):1291-1299. doi:10.1007/s00590-021-03103-z.
[15]	TOUBAN B M, SAYEGH M J, GALINA J, et al. Computed tomography measured psoas cross sectional area is associated with bone mineral density measured by dual energy X-ray absorptiometry[J]. J Clin Densitom, 2022, 25(4):592-598. doi:10.1016/j.jocd.2022.04.001.
[16]	谭波, 胡豇, 卢冰, 等. 骨质疏松症患者血清H₂S的变化及临床意义[J]. 天津医药, 2022, 50(8):832-835.
	TAN B, HU J, LU B, et al. Changes of serum H₂S in patients with osteoporosis and its clinical significance[J]. Tianjin Med J, 2022, 50(8):832-835. doi:10.11958/20212020.
[17]	田爱现, 马剑雄, 马信龙, 等. 极外侧路径下椎体间融合术与传统开放后路椎体间融合术治疗椎间盘突出的效果比较[J]. 中国中西医结合外科杂志, 2023, 29(3):317-321.
	TIAN A X, MA J X, MA X L et al. Perioperative efficacy of extreme lateral interbody fusion versus traditional open posterior interbody fusion for disc herniation[J]. Chinese Journal of Surgery of Integrated Traditional and Western Medicine, 2023, 29(3):317-321. doi:10.3969/j.issn.1007-6948.2023.03.006.
[18]	JONES C, OKANO I, SALZMANN S N, et al. Endplate volumetric bone mineral density is a predictor for cage subsidence following lateral lumbar interbody fusion:a risk factor analysis[J]. Spine J, 2021, 21(10):1729-1737. doi:10.1016/j.spinee.2021.02.021.
[19]	HUANG W, GONG Z, ZHENG C, et al. Preoperative assessment of bone density using MRI-based vertebral bone quality score modified for patients undergoing cervical spine surgery[J]. Global Spine J, 2024, 14(4):1238-1247. doi:10.1177/21925682221138261.
[20]	傅赛琼, 常磊, 张明彦, 等. 老年腰椎退行性疾病患者MIS-TLIF术后融合器后移的影响因素[J]. 中国老年学杂志, 2022, 42(7):1637-1640.
	FU S Q, CHANG L, ZHANG M Y, et al. Influence factors of fusion apparatus retraction in elderly patients with lumbar degenerative diseases after MIS-TLIF surgery[J]. Chinese Journal of Gerontology, 2022, 42(7):1637-1640. doi:10.3969/j.issn.1005-9202.2022.07.031.
[21]	YAO Y C, CHAO H, KAO K Y, et al. CT Hounsfield unit is a reliable parameter for screws loosening or cages subsidence in minimally invasive transforaminal lumbar interbody fusion[J]. Sci Rep, 2023, 13(1):1620. doi:10.1038/s41598-023-28555-7.
[22]	WU H, SHAN Z, ZHAO F, et al. Poor bone quality,multilevel surgery,and narrow and tall cages are associated with intraoperative endplate injuries and late-onset cage subsidence in lateral lumbar interbody fusion:a systematic review[J]. Clin Orthop Relat Res, 2022, 480(1):163-188. doi:10.1097/CORR.0000000000001915.
[23]	袁照, 梁体洪, 孙红, 等. 采用椎间融合器实施PLIF的LDD患者术后椎间融合器下沉影响因素研究进展[J]. 山东医药, 2023, 63(6):96-100.
	YUAN Z, LIANG T H, SUN H, et al. Research progress on the influencing factors of post-operative fusion organ sinking in LDD patients undergoing PLIF with interbody fusion organ[J]. Shandong Medicine Journal, 2023, 63(6):96-100. doi:10.3969/j.issn.1002-266X.2023.06.024.

组别			n		年龄								性别						BMI/（kg/m²）			病程/月
组别			n		<60岁				≥60岁				男			女			BMI/（kg/m²）			病程/月
无沉降组			121		65（53.72）				56（46.28）				60（49.59）			61（50.41）			23.87±2.13			45.76±8.34
沉降组			57		20（35.09）				37（64.91）				23（40.35）			34（59.65）			24.01±2.08			46.84±8.14
χ²或t					5.391^＊								1.328						0.412			0.814
组别		合并症															疾病类型
组别		高血压					糖尿病			高脂血症				骨质疏松症			腰椎间盘突出症				腰椎滑脱		腰椎管狭窄
无沉降组		29（23.97）					27（22.31）			24（19.83）				30（24.79）			34（28.10）				41（33.88）		46（38.02）
沉降组		15（26.32）					14（24.56）			13（22.81）				24（42.11）			23（40.35）				15（26.32）		19（33.33）
χ²		0.115				0.110				0.208				5.495^＊			2.754
组别	手术节段											融合器长度/mm			融合器高度/mm			融合器接触面积/%		手术时间/min			术中出血量/mL
组别	L_2—3			L_3—4				L_4—5			L₅—S₁	融合器长度/mm			融合器高度/mm			融合器接触面积/%		手术时间/min			术中出血量/mL
无沉降组	26（21.49）			25（20.66）				20（16.53）			50（41.32）	8.99±1.21			10.64±2.12			34.5±2.3		175.34±34.38			121.35±35.85
沉降组	2（3.51）			4（7.02）				16（28.07）			35（61.40）	9.35±1.18			11.21±2.24			35.6±2.4		181.58±34.30			131.23±45.34
χ²或t	18.213^＊＊											1.871			1.670			2.787^＊＊		1.131			1.572

组别			n		年龄								性别						BMI/（kg/m²）			病程/月
组别			n		<60岁				≥60岁				男			女			BMI/（kg/m²）			病程/月
无沉降组			121		65（53.72）				56（46.28）				60（49.59）			61（50.41）			23.87±2.13			45.76±8.34
沉降组			57		20（35.09）				37（64.91）				23（40.35）			34（59.65）			24.01±2.08			46.84±8.14
χ²或t					5.391^＊								1.328						0.412			0.814
组别		合并症															疾病类型
组别		高血压					糖尿病			高脂血症				骨质疏松症			腰椎间盘突出症				腰椎滑脱		腰椎管狭窄
无沉降组		29（23.97）					27（22.31）			24（19.83）				30（24.79）			34（28.10）				41（33.88）		46（38.02）
沉降组		15（26.32）					14（24.56）			13（22.81）				24（42.11）			23（40.35）				15（26.32）		19（33.33）
χ²		0.115				0.110				0.208				5.495^＊			2.754
组别	手术节段											融合器长度/mm			融合器高度/mm			融合器接触面积/%		手术时间/min			术中出血量/mL
组别	L_2—3			L_3—4				L_4—5			L₅—S₁	融合器长度/mm			融合器高度/mm			融合器接触面积/%		手术时间/min			术中出血量/mL
无沉降组	26（21.49）			25（20.66）				20（16.53）			50（41.32）	8.99±1.21			10.64±2.12			34.5±2.3		175.34±34.38			121.35±35.85
沉降组	2（3.51）			4（7.02）				16（28.07）			35（61.40）	9.35±1.18			11.21±2.24			35.6±2.4		181.58±34.30			131.23±45.34
χ²或t	18.213^＊＊											1.871			1.670			2.787^＊＊		1.131			1.572

组别	n	腰椎CT 值/HU	椎间隙高度/mm	节段性前凸角/°	腰椎前凸角/°	骨盆入射角/°	骨盆倾斜角/°	螺钉内倾角/°	螺钉尾倾角/°
无沉降组	121	131.03±11.19	12.30±1.24	17.99±1.87	45.28±13.59	49.14±9.32	32.85±4.99	13.49±2.87	11.85±3.67
沉降组	57	110.80±10.92	13.57±1.15	20.45±1.95	47.25±12.24	48.70±8.24	31.68±5.26	13.12±2.98	11.25±3.87
t		11.337^＊＊	6.562^＊＊	8.070^＊＊	0.936	0.298	1.423	0.771	0.982

组别	n	腰椎CT 值/HU	椎间隙高度/mm	节段性前凸角/°	腰椎前凸角/°	骨盆入射角/°	骨盆倾斜角/°	螺钉内倾角/°	螺钉尾倾角/°
无沉降组	121	131.03±11.19	12.30±1.24	17.99±1.87	45.28±13.59	49.14±9.32	32.85±4.99	13.49±2.87	11.85±3.67
沉降组	57	110.80±10.92	13.57±1.15	20.45±1.95	47.25±12.24	48.70±8.24	31.68±5.26	13.12±2.98	11.25±3.87
t		11.337^＊＊	6.562^＊＊	8.070^＊＊	0.936	0.298	1.423	0.771	0.982

变量	β	SE	Wald χ²	P	OR	95%CI
年龄	0.536	0.197	7.403	0.026	1.709	1.162~2.515
手术节段	0.641	0.215	8.889	0.012	1.898	1.246~2.893
椎间隙高度	0.685	0.203	11.386	<0.001	1.984	1.333~2.953
节段性前凸角	0.988	0.312	10.028	<0.001	2.686	1.457~4.951
腰椎CT值	-0.789	0.192	16.887	<0.001	0.454	0.312~0.662
常数项	-0.421	0.184	5.235	0.045	-	-
