Effect of electroacupuncture on the activation of microglia in rats with hypoxia-ischemia brain damage by regulating Nrf2/HO-1 pathway

doi:10.11958/20220792

Abstract

Abstract:

Objective To explore the effect of electroacupuncture regulating nuclear factor E2-related factor 2 (Nrf2)/heme oxygenase 1 (HO-1) pathway on the activation of microglia in rats with hypoxia-ischemia brain damage (HIBD). Methods Forty SD rats were randomly divided into the sham operation group, the model group, the electroacupuncture group and the electroacupuncture + all-trans retinoic acid group. Rat model of HIBD was established by common carotid artery ligation and hypoxia in the three groups except the sham operation group. In the sham operation group, only the left common carotid artery and vagus nerve were exposed no ligation and hypoxia treatment. After modeling, electroacupuncture stimulation at Baihui point was given to the electroacupuncture group. Rats in the electroacupuncture + all-trans retinoic acid group were given all-trans retinoic acid (7 mg/kg) intraperitoneally after electroacupuncture stimulation. Neurobehavioral scores of rats were evaluated by Longa score. Open field and water maze experiments were used to detect the behavioral changes and cognitive function of rats. TUNEL method was used to detect the apoptosis of nerve cells. Immunohistochemical method was used to detect the expression of microglia marker protein ionized calcium binding adapter molecule 1 (Iba1) in rat brain. Levels of interleukin-10 (IL-10), IL-1β, reactive oxygen species (ROS) and malondialdehyde (MDA) in rat brain were detected with kits. Western blot assay was used to detect the expression levels of CD68, inducible nitric oxide synthase (iNOS), arginase and Nrf2/HO-1 pathway related proteins in brain tissue. Results Compared with the sham operation group, the neurobehavioral score, the escape latency, cerebral cortex nerve cell apoptosis rate, the expression levels of Iba1, IL-1β and MDA, ROS fluorescence intensity, CD68 and iNOS were increased in the model group, and the exercise distance, number of standing times, the number of crossing platform times, levels of IL-10, arginase, Nrf2 and HO-1 decreased (P<0.05). Electroacupuncture can reduce neurobehavioral score, the escape latency, nerve cell apoptosis rate, expression levels of Iba1, IL-1β, MDA, ROS fluorescence intensity, CD68 and iNOS, and increase exercise distance, number of standing times, number of crossing platform times, levels of IL-10, arginase, Nrf2 and HO-1 (P<0.05). The effect of electroacupuncture on the above indicators could be reversed in the electroacupuncture + all-trans retinoic acid group. Conclusion Electroacupuncture may inhibit the hyperactivation of microglia in rats with HIBD by activating the Nrf2/HO-1 pathway, and promote the transition from M1 type to M2 type.

Key words: hypoxia-ischemia, brain, animals, newborn, electroacupuncture, nuclear factor NF-E2-related factor, heme oxygenase 1, microglia

CLC Number:

R285.5

Figures/Tables 7

References 18

[1]	TSUJI S, DI MARTINO E, MUKAI T, et al. Aggravated brain injury after neonatal hypoxic ischemia in microglia-depleted mice[J]. J Neuroinflammation, 2020, 17(1):111-125. doi:10.1186/s12974-020-01792-7.
[2]	ZHOU D, JI L, CHEN Y. TSPO modulates IL-4-induced microglia/macrophage m2 polarization via ppar-γ pathway[J]. J Mol Neurosci, 2020, 70(4):542-549. doi:10.1007/s12031-019-01454-1.
[3]	CHU X, CAO L, YU Z, et al. Hydrogen-rich saline promotes microglia M2 polarization and complement-mediated synapse loss to restore behavioral deficits following hypoxia-ischemic in neonatal mice via AMPK activation[J]. J Neuroinflammation, 2019, 16(1):104-118. doi:10.1186/s12974-019-1488-2.
[4]	MA Z, ZHANG Z, BAI F, et al. Electroacupuncture pretreatment alleviates cerebral ischemic injury through α7 nicotinic acetylcholine receptor-mediated phenotypic conversion of microglia[J]. Front Cell Neurosci, 2019, 13(1):537-550. doi:10.3389/fncel.2019.00537.
[5]	袁丹, 常能彬, 梁玉兰, 等. 谷红注射液对新生大鼠脑缺氧缺血损伤的保护作用研究[J]. 中国中医急症, 2019, 28(8):1374-1377.
	YUAN D, CHANG N B, LIANG Y L, et al. Protective effect of guhong injection on hypoxic-ischemic brain injury in neonatal rats[J]. Journal of Emergency in Traditional Chinese Medicine, 2019, 28(8):1374-1377. doi:10.3969/j.issn.1004-745X.2019.08.015.
[6]	林斯革, 陈皓, 蔡雪峰, 等. MiR-153通过调控Keap1/Nrf2/HO-1信号通路改善脑缺血再灌注后的炎症反应及保护神经元功能的研究[J]. 免疫学杂志, 2020, 36(9):737-747.
	LIN S G, CHEN H, CAI X F, et al. MiR-153 improves inflammatory response and protects neuron function after cerebral ischemia-reperfusion by regulating Keap1/Nrf2/HO-1 signaling pathway[J]. Immunological Journal, 2020, 36(9):737-747. doi:10.13431/j.cnki.immunol.j.20200116.
[7]	王云涛, 任立洁, 单世民, 等. 脊髓Nrf2/HO-1信号通路在氢减轻大鼠炎性痛中的作用[J]. 中华麻醉学杂志, 2018, 38(4):447-450.
	WANG Y T, REN L J, SHAN S M, et al. Role of spinal Nrf2/HO-1 signaling pathway in hydrogen-induced reduction of inflammatory pain in rats[J]. Chinese Journal of Anesthesiology, 2018, 38(4):447-450. doi:10.3760/cma.j.issn.0254-1416.2018.04.017.
[8]	郭静, 吴芳, 袁云, 等. 天麻素对缺血缺氧脑损伤新生大鼠小胶质细胞Sirt3表达的影响[J]. 神经解剖学杂志, 2020, 36(1):45-50.
	GUO J, WU F, YUAN Y, et al. The effects of gastrodin on the expression of Sirt3 in microglia of hypoxic-ischemic brain damage rats[J]. Chinese Journal of Neuroanatomy, 2020, 36(1):45-50. doi:10.16557/j.cnki.1000-7547.2020.01.008.
[9]	黄海英, 陈尚明, 赵建美. 新生大鼠缺血缺氧性脑损伤组织中HAX-1、Caspase-3、bcl-2表达变化及意义[J]. 山东医药, 2015, 55(30):36-37.
	HUANG H Y, CHEN S M, ZHAO J M, et al. Changes and significance of HAX-1,Caspase-3 and bcl-2 expression in neonatal rats with hypoxic ischemic brain injury[J]. Shandong Medical Journal, 2015, 55(30):36-37. doi:10.3969/j.issn.1002-266X.2015.30.011.
[10]	杨蕾, 翟茜, 江涛, 等. 电针预处理对脑缺血再灌注后小胶质细胞活化状态的影响[J]. 现代生物医学进展, 2015, 15(20):3826-3829.
	YANG L, ZHAI Q, JIANG T, et al. Effect of electroacupuncture pretreatment on the state of microglial activation after cerebral ischemia and reperfusion in rat[J]. Progress in Modern Biomedicine, 2015, 15(20):3826-3829. doi:10.13241/j.cnki.pmb.2015.20.007.
[11]	MEI Z G, HUANG Y G, FENG Z T, et al. Electroacupuncture ameliorates cerebral ischemia/ reperfusion injury by suppressing autophagy via the SIRT1-FOXO1 signaling pathway[J]. Aging(Albany NY), 2020, 12(13):13187-13205. doi:10.18632/aging.103420.
[12]	THOMI G, SURBEK D, HAESLER V, et al. Exosomes derived from umbilical cord mesenchymal stem cells reduce microglia-mediated neuroinflammation in perinatal brain injury[J]. Stem Cell Res Ther, 2019, 10(1):105-120. doi:10.1186/s13287-019-1207-z.
[13]	张弦, 黄国付, 邹璟, 等. 电针预处理对脑缺血后小胶质细胞活化影响的研究进展[J]. 中医药导报, 2017, 23(6):77-79,82.
	ZHANG X, HUANG G F, ZOU J, et al. Research progress on the effect of electroacupuncture preconditioning on the activation of microglia after cerebral ischemia[J]. Guiding Journal of Traditional Chinese Medicine and Pharmacology, 2017, 23(6):77-79,82.
[14]	叶任之, 张铃, 蔡巧燕, 等. 基于p38MAPK/Nrf2/HO-1通路探讨清达颗粒对脂多糖诱导活化的小胶质细胞抗氧化作用研究[J]. 中西医结合心脑血管病杂志, 2020, 18(11):1700-1706.
	YE R Z, ZHANG L, CAI Q Y, et al. Anti-oxidation of qingda granules on lipopolysaccharide-induced microglia based on p38MAPK/Nrf2/HO-1 pathway[J]. Chinese Journal of Integrative Medicine on Cardio/Cerebrovascular Disease, 2020, 18(11):1700-1706. doi:10.12102/ji.ssn.1672-1349.2020.11.007.
[15]	LV C, MAHARJAN S, WANG Q, et al. α-Lipoic acid promotes neurological recovery after ischemic stroke by activating the Nrf2/HO-1 pathway to attenuate oxidative damage[J]. Cell Physiol Biochem, 2017, 43(3):1273-1287. doi:10.1159/000481840.
[16]	SALMAN M, TABASSUM H, PARVEZ S. tannic acid provides neuroprotective effects against traumatic brain injury through the PGC-1α/Nrf2/HO-1 pathway[J]. Mol Neurobiol, 2020, 57(6):2870-2885. doi:10.1007/s12035-020-01924-3.
[17]	HE D, FU S, ZHOU A, et al. Camptothecin regulates microglia polarization and exerts neuroprotective effects via activating AKT/Nrf2/HO-1 and inhibiting NF-κB pathways in vivo and in vitro[J]. Front Immunol, 2021, 12(1):619761-619771. doi:10.3389/fimmu.2021.619761.
[18]	ZHOU C H, XUE F, XUE S S, et al. Electroacupuncture pretreatment ameliorates PTSD-Like behaviors in rats by enhancing hippocampal neurogenesis via the Keap1/Nrf2 antioxidant signaling pathway[J]. Front Cell Neurosci, 2019, 13(1):275-283. doi:10.3389/fncel.2019.00275.

组别		旷场实验
组别		运动路程（cm）		站立次数（次）
假手术组		2 253.30±230.41		70.16±6.03
模型组		852.17±118.80^a		42.57±3.22^a
电针组		1 695.16±161.30^ab		61.07±4.04^ab
电针+全反式维甲酸组		1 233.46±127.14^abc		48.20±3.26^abc
F		133.590^＊＊		84.406^＊＊
组别	水迷宫实验
组别	穿越平台次数（次）		逃避潜伏期（s）
假手术组	8.93±1.02		14.10±1.12
模型组	2.04±0.50^a		27.96±2.17^a
电针组	6.25±0.71^ab		18.40±1.22^ab
电针+全反式维甲酸组	4.37±0.60^abc		22.70±1.46^abc
F	158.019^＊＊		146.818^＊＊

组别		旷场实验
组别		运动路程（cm）		站立次数（次）
假手术组		2 253.30±230.41		70.16±6.03
模型组		852.17±118.80^a		42.57±3.22^a
电针组		1 695.16±161.30^ab		61.07±4.04^ab
电针+全反式维甲酸组		1 233.46±127.14^abc		48.20±3.26^abc
F		133.590^＊＊		84.406^＊＊
组别	水迷宫实验
组别	穿越平台次数（次）		逃避潜伏期（s）
假手术组	8.93±1.02		14.10±1.12
模型组	2.04±0.50^a		27.96±2.17^a
电针组	6.25±0.71^ab		18.40±1.22^ab
电针+全反式维甲酸组	4.37±0.60^abc		22.70±1.46^abc
F	158.019^＊＊		146.818^＊＊

组别	细胞凋亡率（%）	Iba1阳性细胞数（个/视野）
假手术组	7.21±1.18	4.12±1.02
模型组	39.16±2.22^a	89.87±9.08^a
电针组	18.69±1.10^ab	40.64±5.36^ab
电针+全反式维甲酸组	23.64±2.25^abc	68.18±6.37^abc
F	278.843^＊＊	179.359^＊＊

组别	细胞凋亡率（%）	Iba1阳性细胞数（个/视野）
假手术组	7.21±1.18	4.12±1.02
模型组	39.16±2.22^a	89.87±9.08^a
电针组	18.69±1.10^ab	40.64±5.36^ab
电针+全反式维甲酸组	23.64±2.25^abc	68.18±6.37^abc
F	278.843^＊＊	179.359^＊＊

组别	IL-1β（mg/g）	IL-10（mg/g）	ROS荧光强度	MDA（mmol/mg）
假手术组	0.015±0.004	0.053±0.004	125.59±18.36	3.98±0.28
模型组	0.050±0.007^a	0.018±0.003^a	284.74±25.87^a	6.67±0.32^a
电针组	0.023±0.005^b	0.042±0.005^ab	180.15±15.36^ab	5.01±0.29^ab
电针+全反式维甲酸组	0.038±0.005^abc	0.030±0.004^abc	227.15±16.50^abc	5.80±0.30^abc
F	42.261^＊＊	69.167^＊＊	60.618^＊＊	73.946^＊＊
